Well-Type Nitriding Furnace For Steel Workpieces Tempering Furnace
Description
Well-Type Nitriding Furnace For Steel Workpieces Tempering Furnace is a continuous operation furnace. The workpiece is placed at the
entrance of the electric furnace by manual or manipulator. The
workpiece passes through the furnace at a constant speed and is
heated to the set temperature. At the exit, it falls into the
quenching pool to complete the quenching treatment. Work is raised
from the pool and into the tempering furnace. In this way, the heat
treatment process of quenching and tempering is completed.
1. Well-Type Nitriding Furnace For Steel Workpieces Tempering Furnace Structure
Pit type tempering furnace is energy-saving cycle operation
furance, which is used for tempering general metal parts in the air
and quenching, annealing, aging heat treatment for aluminum alloy
castings ,piston, aluminum and other light alloy parts.
2.Well-Type Nitriding Furnace For Steel Workpieces Tempering Furnace Preparations
Preparations before opening the furnace
a. Remove the carbon black in the furnace tank and check the
sealing gasket.
b. Check the circulating fan and motor, add grease to the bearing,
and pass water through the cooling water jacket.
c. Check the position of the thermocouple and the hydraulic lifting
mechanism.
d. Check the titrator, methanol, and kerosene reservoirs.
3. Well-Type Nitriding Furnace For Steel Workpieces Tempering Furnace Technical Parameter
| Model | IRIS-JQ65 |
| Electric furnace power | 65kw |
| Input voltage | 480v 60 HZ |
| Effective size | Ф700mm*1000mm |
| Maximum temperature | 750℃ |
| Number of temperature control zones | 1 zone |
| Temperature control accuracy | ≤±2℃ |
| Furnace Size | 1600mm×1800mm×2100 mm |
| Furnace Weight | 2800kg |
| Productivity | 100kg/h |
| Heating method | High temperature resistance tape |
| Temperature control method | Intelligent digital display instrument and PID temperature control;
with over temperature alarm |
| Heating time | less than 1.2 hours |
Company information
Contribute to the foreign trade and build an excellent supplier in
Central plains of China, Zhengzhou Iris Imp & Exp Co., Ltd follows
the "professional foreign trade, happy business" spirit of
enterprise, and contribute to export the Chinese industrial
machinery in overseas market. Our business scope includes: KGPS
series thyristor medium frequency heating equipments (steel shell
melting furnace, aluminum shell melting furnace, heating furnace),
A two SCR series, parallel power supply, IGBT MF, HF super
audio-frequency heating equipments (melting furnace, forging
furnace, hardening furnace, welding machine, heating furnace),
Electric resistance furnace, CNC quenching tool machines, cooling
systems and ancillary transformer and other equipments
.
